1. KNX Software Functions
Dimming control: Supports different dimming curves, dimming speeds, and uniform dimming time
Memory & delay functions: Equipped with memory function, ON/OFF delay, and staircase time function (with/without manual OFF function)
Scene & central control: Allows storage/retrieval of up to 8 scenes (with stored brightness values) and offers central control function
Advanced logic: Features logic operation, priority control, and blocking function
Status & recovery: Provides real-time status feedback and preset behavior settings for bus voltage recovery
2. Device Specifications
Switch contact: Used for switching electronic ballasts/transformers
Nominal voltage: AC 230 V, 50-60 Hz
Nominal current: 16 A, cosϕ = 0.6
Switching capacity: AC 230 V, 3600 W, cosϕ = 1
Capacitive load: AC 230 V, 16 A, 200 µF
Load compatibility (by lamp type):
Incandescent lamps: AC 230 V, max. 3600 W
Halogen lamps: AC 230 V, max. 2500 W
Fluorescent lamps: AC 230 V, max. 3600 VA (uncompensated); AC 230 V, max. 2500 VA (with parallel compensation)
LV-halogen lamps (with wound transformer): max. 2000 VA
0-10 V interface: Current range 0.12-100 mA; Voltage range DC 0-10 V
Device width: 4 HP (approx. 72 mm)
Package contents: Includes bus connecting terminal and cable cover
